Grundfos MAGNA1 Instructions

English (GB)
3
1. Symbols used in this document
Warning
If these safety instructions are not observed, it may result in
personal injury.
Warning
If these instructions are not observed, it may lead to electric shock
with consequent risk of serious personal injury or death.
Warning
The surface of the product may be so hot that it may cause burns
or personal injury.
Warning
Risk of dropping objects which may cause personal injury.
Warning
Escaping vapour involves the risk of personal injury.

Grundfos MAGNA1 Specifications

General

Pump Type	Circulator Pump
Flow Range	0.5 - 12 m³/h
Maximum Flow	12 m³/h
Maximum Head	10 m
Maximum Liquid Temperature	110°C
Maximum Operating Pressure	10 bar
Power Supply	230 V, 50/60 Hz
Enclosure Class	IP42
Insulation Class	F
Pump Housing	Cast Iron
Installation Length	180 mm
Series	MAGNA1
Energy Efficiency Class	A
Liquid Temperature Range	2°C to 110°C
Approvals	CE, EAC
Ambient Temperature Range	0 .. 40 °C
