2. Type key
3. Pumped liquids
Code Example (D) 32 -100 (F) 220
Type range
MAGNA1
D
Single-head
pump
Twin-head pump
Nominal diameter (DN)
of inlet and outlet ports
[mm]
Maximum head [dm]
F
Pipe connection
Threaded
Flange
Port-to-port length [mm]
Warning
The pump must not be used to pump flammable, combustible or
explosive liquids.

Grundfos MAGNA1 Specifications

General

Pump Type	Circulator Pump
Flow Range	0.5 - 12 m³/h
Maximum Flow	12 m³/h
Maximum Head	10 m
Maximum Liquid Temperature	110°C
Maximum Operating Pressure	10 bar
Power Supply	230 V, 50/60 Hz
Enclosure Class	IP42
Insulation Class	F
Pump Housing	Cast Iron
Installation Length	180 mm
Series	MAGNA1
Energy Efficiency Class	A
Liquid Temperature Range	2°C to 110°C
Approvals	CE, EAC
Ambient Temperature Range	0 .. 40 °C
