English (GB)
5
1. General information
1.1 Target group
These installation and operating instructions are
intended for professional as well as non-professional
users.
1.2 Hazard statements
The symbols and hazard statements below may
appear in Grundfos installation and operating
instructions, safety instructions and service
instructions.
The hazard statements are structured in the
following way:
1.3 Notes
The symbols and notes below may appear in
Grundfos installation and operating instructions,
safety instructions and service instructions.
2. Receiving the product
2.1 Inspecting the product
Check that the product received is in accordance
with the order.
Check that the voltage and frequency of the product
match the voltage and frequency of the installation
site. See section 6.4.1 Nameplate.
2.2 Scope of delivery
The box contains the following items:
• 1 Grundfos SCALA2 pump
• 1 quick guide
• 1 safety instructions booklet.
3. Installing the product
3.1 Location
The pump can be installed indoors or outdoors, but it
must not be exposed to frost.
We recommend that you install the pump near a
drain or in a drip tray connected to a drain in order to
lead away possible condensation from cold surfaces.
3.1.1 Minimum space
The pump requires a minimum space of 430 x 215 x
325 mm (17 x 8.5 x 12.8 inches).
Even though the pump does not require much space,
we recommend that you leave enough space for
service and maintenance access.
3.1.2 Installing the product in frosty environment
Protect the pump from freezing if it is to be installed
outdoors where frost may occur.
DANGER
Indicates a hazardous situation which, if
not avoided, will result in death or serious
personal injury.
WARNING
Indicates a hazardous situation which, if
not avoided, could result in death or
serious personal injury.
CAUTION
Indicates a hazardous situation which, if
not avoided, could result in minor or
moderate personal injury.
SIGNAL WORD
Description of hazard
Consequence of ignoring the warning.
- Action to avoid the hazard.
Observe these instructions for
explosion-proof products.
A blue or grey circle with a white graphical
symbol indicates that an action must be
taken.
A red or grey circle with a diagonal bar,
possibly with a black graphical symbol,
indicates that an action must not be taken
or must be stopped.
If these instructions are not observed, it
may result in malfunction or damage to the
equipment.
Tips and advice that make the work easier.
Install the pump in such a way that no
undesirable collateral damage can arise
due to leakage.
If the unlikely event of an internal leakage
occurs, the liquid will be drained through
the bottom of the pump.
