4. Identification
4.1 Nameplate
The nameplate states the operating data and
approvals applying to the pump. The nameplate is
fitted to the side of the motor housing close to the
cable entry.
Fix the extra nameplate supplied with the pump to
the cable end in the control cabinet.
Fig. 3 Nameplate
TM04 3297 0716TM07 5414 3919
Type: SLV.80.80.110.EX.2.51D
Model: 9687208500000001
P.c. 0845 IP68
44.9 90
40
12.5 11.0
2950 0.89
50
0197
180
22.4-20.8
380-415
3 ~
20 m
Hmax:
Motor:
P1:
Qmax:
Tmax.:
n:
kg
min
kW
V
A
mmh/
3
C
kW
P2:
-1
V
A
Hz Insul.class:
Weight: EN 12050-1
Made in Tatabanya, Hungary
98808079
96771279
3
5
6
9
10
12
8
7
11
17
15
19
13
14
16
22
24
21
23
4
1
2
18
20
25
H
CE0344
II2G
KEMA 08ATEX 0125X
Ex db h llB T4,T3 Gb
&RVij
DK-8850 Bjerringbro, Denmark
Pos. Description
1Approvals
2 Explosion protection certificate No.
3 Ex description
4 Type designation
5 Model number
6 Production code (year and week)
7 Enclosure class to IEC
8 Maximum installation depth
9 Maximum head
10 Maximum flow rate
11 Number of phases
12 Maximum liquid temperature
13 Rated input power
14 Shaft power
15 Rated speed
16 Power factor
17 Rated voltage, D
18 Rated current, D
19 Rated voltage, Y
20 Rated current, Y
21 Frequency
22 Insulation class
23 Approval
24 Weight without cable
25 Country of production
