6. First-time setup via the "Start-up Guide"
At each step, if defaulted to the correct selection, press
the [Down] button to continue to the next step. If the se-
lection needs to be changed, press OK and use the [Up]
and [Down] buttons until the correct selection is highlight-
ed. Press OK again, then press the [Down] button to con-
tinue to the next step.
1. Press OK to begin the Start-up Guide.
Welcome to the CUE Start-
up guide. Press OK to
continue
Start-up Guide
TM077488
Welcome screen
2. Press OK to select the desired language.
1(1)
Please select language:
English
Start-up Guide
TM077489
Language
3. Select the
"Imperial" unit type.
1(1)
Please select the units used
for setup
Imperial
Start-up Guide
TM081117
Units
Imperial units are, for example, psi, hp and gpm as opposed to
metric units like bar, kW and m
3
/h.
4. Select the SP pump family.
1(1)
Please select the pump you
are running or select other
for unrestricted settings
SP, SPE
Start-up Guide
TM081118
Pump type
5. Select "Asynchronous motor" as the motor type.
1(1)
Please select the motor of
the pump or select “skip
motor setup”
Asynchronous motor
Start-up Guide
TM077492
Motor type
6. Enter the motor power found on the motor nameplate.
1(1)
Enter Total Motor Power:
1.50 hp
Start-up Guide
TM081121
Motor power
7. Enter a nominal voltage closest to the actual measured supply
voltage.
1(1)
Enter Total Motor Voltage:
230 V
Start-up Guide
TM081122
Motor voltage
The actual supply voltage must be within the voltage
range of the motor.
8. Enter the motor frequency and the maximum continuous current
(MCC).
1(1)
Select Motor Frequency:
60Hz
Start-up Guide
Max Cont. Current (MCC):
5.1A
TM081123
Motor frequency and MCC
The motor frequency is defaulted to 60 Hz. Press the [Down]
button to keep the default value.
As MCC, enter the SFA value found on the motor nameplate.
