17.
Select
"4-20mA"
for the feedback sensor type.
1(1)
Feedback Sensor T
ype
(T
erminal 54)
4-20mA
Start-up Guide
TM077551
Feedback sensor type
18.
Enter
"60 psi"
as the setpoint.
1(1)
Enter Setpoint
60 psi
Start-up Guide
TM081
129
Setpoint
19.
By pressing
OK
, the setup is completed.
1(1)
Basic set-up is
completed!
Start-up Guide
TM077508
Setup completed
12
English (US)
11
13
