Grundfos UPE 32-80 User Manual

25
10. Technical data
Supply voltage
1 x 230-240 V –10%/+6%, 50 Hz, PE.
Motor protection
The pump requires no external motor protection.
Enclosure class
IP 42.
Insulation class
H.
Relative air humidity
Maximum 95%.
Ambient temperature
0°C to +40°C.
Temperature class
TF110 to CEN 335-2-51.
Liquid temperature
Maximum +110°C.
Continuously: +15°C to +95°C.
Pumps in domestic hot-water systems:
Continuously: +15°C to +60°C.
To avoid condensation in the terminal box and the
stator, the pumped liquid temperature must always
be higher than the ambient temperature. See the ta-
ble below:
System pressure
Pipe connection:
• UPE 25-40, 25-40 A, 25-60, 25-60 A, 25-80,
32-40, 32-60 and 32-80: Maximum 10 bar.
Flange connection:
• UPE 32-80 F, 40-80 F and 50-80 F: PN 6
(maximum 6 bar) or PN 10 (maximum 10 bar).
• The system pressure is indicated on the pump
flanges.
Inlet pressure
The following minimum pressures must be available
at the pump inlet during operation:
EMC (electromagnetic compatibility)
EN 61 000-6-2.
EN 61 000-6-3.
Sound pressure level
The sound pressure level of the pump is lower than
43 dB(A).
Leakage current
The pump mains filter will cause a discharge current
to earth during operation. I
leakage
< 3.5 mA.
Inputs and outputs of expansion modules
Ambient
temperature
[°C]
Liquid temperature
Min. [°C] Max. [°C]
15 15 110
20 20 110
25 25 110
30 30 110
35 35 90
40 40 70
Pump type
Liquid temperature
75°C 90°C 110°C
m head m head m head
UPE xx-40 0.5 2.8 11.0
UPE xx-60 0.5 2.8 11.0
UPE xx-80 0.5 2.8 11.0
Start/stop input
External potential-free switch.
Contact load: 5 V, 0.1 mA.
Screened cable.
Loop resistance:
Maximum 130 Ω/km.
Logical levels:
Logical zero: U < 1.5 V.
Logical one: U > 4.0 V.
Max. curve in-
put
Min. curve input
Input for analog
0-10 V signal
External signal: 0-10 VDC.
Maximum load: 0.1 mA.
Screened cable.
Fault signal
module output
Internal potential-free change-
over contact.
Maximum load: 250 V, 2 A AC1.
Minimum load: 5 V, 1 mA.
Screened cable.
Bus input
Grundfos GENIbus protocol,
RS-485.
Screened cable.
Lead cross section: 0.25 - 1 mm².
Cable length: Maximum 1200 m.

Grundfos UPE 32-80 Specifications

General

Motor Type	ECM (Electronically Commutated Motor)
Pipe Connection	Flanged
Maximum Operating Pressure	10 bar
Pump Housing	Cast iron
Enclosure Class	IP44
Insulation Class	F
Connection Size	DN 32
Power Supply	230 V
Control Type	Proportional pressure, constant pressure, constant curve
Approvals	CE, EAC
Rated Voltage	400 V
Pump Type	Circulator Pump
Head	Up to 8 m
