3.3 Pumped liquids
WARNING
Electric shock
Death or serious personal injury
‐ For indoor use only.
‐ This pump has not been investigated for use in
swimming pool or marine areas.
WARNING
Fire or explosion hazard
Death or serious personal injury
‐ The pump must not be used for the transfer of
flammable liquids such as diesel oil, gasoline and
similar liquids.
The product is suitable for pumping clean, thin, non-aggressive and
non-explosive liquids without solid particles or fibers or mineral oils.
If required, 50 % of the volume solution of glycol and water can be
used. However, a decrease in pump performance may occur due to
an increase in the viscosity of the solution. Contact the
manufacturer for information regarding suitability of the pump for
pumping other liquids.
The pump is designed to circulate water from 36 to 230 °F (2 to 110
°C) up to a maximum pressure of 175 psi (12 bar), depending on
the variant.
3.4 Identification
3.4.1 Nameplate
XXX XX: XXXXXXXXX
Made in XXXXXXX
Model:
pMax: XXX PSI / XXXXX Mpa
tMAX LIQUID: XXX°F / XXX°C
tMAX AMB: XXX°F / XXX°C
Non-submersible pump
Pompe non immergée
Electronically Protected
PN:XXXXXXXX
SN:XXXXXXXX
PC:XXXXXXX
Ver:X-XXXX
Grundfos Holding A/S
DK-8850 Bjerringbro
Denmark
Enclosure type 2
Boitier de type 2
1Ph 115V 60Hz
Max
Min
X.XX
X.XX
XX
XX
Watt
Amp
XXXXXXXXXXXXXXXXXXXXXXXXXXX
XXXXX
10
12
13
14
15
11
6
7
8
9
5
2
1
3
4
18
19
21
20
17
16
TM082374
Pos. Description
1 Min. current consumption
2 Max. current consumption
3 Min. power consumption
4 Max. power consumption
5 Number of phases, voltage and frequency
6 Product number
7 Serial number
8 Factory code and production code (year and week)
9 Version letter and update number
10 Pump model
11 Enclosure class
12 Max. ambient temperature
13 Max. liquid temperature
14 Max. system pressure
15 Enclosure type
16 Country of origin
17 Grundfos address
18 Approvals
19 FCC radio approval ID
20 Combined legal product code
21 Data matrix
6
English (US)
