3.4.2 Type key
Example: UPMS 20-58 F 165 115V CB 9H
Code Explanation Designation
UPMS Standard Pump type
15 R 1/2" / G 1"
Nominal diameter20 R 3/4" / G 1 1/4"
25 R 1" / G 1 1/2"
58 19 ft (5.8 m)
Max. head
78 26 ft (7.8 m)
[ ] Cast iron
Pipe connection
[ ] Union
F Flange
Pump housing
N Stainless steel
CIL3 CIL3
130 130 mm
Port to port
150 150 mm
165 165 mm
A PWM profile, heating
External signal
R 0-10 V
115V 115 V Voltage
[ ] No conduit box
Power connection
CB Conduit box
3H 3 o'clock (right)
Conduit box position
9H 9 o'clock (left)
0H 12 o'clock (top)
OEM OEM circulator Customer code
3.5 Approvals
Pump model
W
A
TER QUALITY
Drinking water system component
NSF/ANSI 61
NSF/ANSI 372
Pumps without
conduit box
✔ -
✔
2)
Pumps with
conduit box
- ✔
✔
2)
2)
It only applies to pumps with pump housing in stainless steel and CIL3.
Any changes or modifications to this equipment not
expressly approved by the party responsible for
compliance could void the user’s authority to operate this
equipment.
4. Receiving the product
4.1 Inspecting the product
CAUTION
Crushing of feet
Minor or moderate personal injury
‐ Wear safety shoes when handling the product.
CAUTION
Sharp element
Minor or moderate personal injury
‐ Wear protective gloves.
1. Make sure that the delivered product corresponds to the order.
2. Make sure that the voltage and frequency of the product match
the voltage and frequency of the installation site.
