Fernbedienung
Cassettendeck
(CCF
8300,
Laufwerk
B)
zum
Wiedergeben
TAPE
1
bzw
TAPE
2
anwahlen.
Fan
inte
UAMP:TYAVIDEO
COD.
TREB/BRIGHTN.
+
ap ap
PHONO
ap
44-
D>
=
schneller
Ruck-
und
Vorlauf
4
=
Reverse-Start
>
=
Normal-Start
REC
@
=
Aufnahme
eb
VIDEO
ll
=
Pause
a=
ap
1d
@
=
Stop
GRUNDI
Mechanischer
Teil:
CCF
8300
Allgemeines
zum
mechanischen
Teil
Vor
Beginn
von
Servicearbeiten
das
Gerat
in
die
Funktion
STOP
bringen,
der
Kopfschlitten
ist
dann
zuriick
gefahren.
(Netzstecker
ziehen)
Die
Zahlen
im
Text
und
bei
den
Abbildungen
sind
mit
den
Positionsnummern
in
der
Ersatzteilliste
CCF
8300
tibereinstimmend,
Ist
den
Positionsnummern
ein
LW
vorgesetzt,
sind
die
Teile
in
der
Ersatzteilliste
CMAY-2/6
aufgefiihrt.
Die
Ersatzteillisten
befinden
sich
am
Ende
dieses
Service-Manuals.
Teile
die
nicht
in
den
Ersatzteillisten
vor-
kommen,
sind
mit
Buchstaben
gekennzeichnet.
Alle
Schrauben,
die
in
Kunststoff
eingedreht
werden,
sollten
erst
gegen
den
Uhrzeigersinn
gedreht
werden,
bis
die
Schraube
den
Gewindeanfang
findet,
erst
dann
die
Schraube
hineindrehen.
Da-
durch
wird
vermieden,
daB
ein
neues
Gewinde
geschnitten
wird.
1.
Gehduse
abnehmen
(Abb.
1)
4Schrauben
a
und
2
Schrauben
b
herausdrehen.
Gehause
¢
nach
oben
wegnehmen.
G
Remote
control
Cassette
deck
(CCF
8300,
drive
mech.
B)
TAPE
1
or
TAPE
2
for
playback
44-
=
fast
rewind
and
fast
forward
4
=
reverse
start
>
=
normal
start
REC
@
=
recording
ll
=
pause
@
=
Stop
Mechanical
Section:
CCF
8300
General
notes
on
the
mechanical
section.
Before
starting
repair
works
set
the
tape
deck
to
STOP
position
so
that
the
head
carrier
is
in
service
position
(disconnect
mains
plug).
The
numbers
in
the
text
and
figures
are
identical
with
the
reference
numbersof
the
CCF
8300
spare
parts
list.
Numbers
with
the
prefix
LW
are
used
for
parts
which
are
listed
in'the
CMAY-2/6
spare
parts
list.
The
spare
parts
lists
are
attached
to
this
Service
Manual
Parts
not
contained
in
the
spare
parts
lists
are
marked
with
let-
ters.
Screws
which
are
driven
into
plastic
parts
should
be
twisted
counter-
clockwise
first
so
that
the
screw
approaches
the
first
thread,
then
tighten
the
screw
to
avoid
cutting
new
threads.
1.
Removal
of
the
cabinet
(Fig.
1)
Undo
4
screws
a
and
2
screws
b.
Lift
the
cabinet
¢
top
and
remove
it.
Fig.
1
