Gryphon Commander - Commander Preamplifier Rear Panel; Balanced and Single-Ended Outputs; Input Connections

26
BALANCED OUTPUT 1 - 2
Balanced, fully discrete, DC-coupled Class A preamplifier outputs to drive power amplifier(s).
SINGLE ENDED OUTPUT
Single-ended, fully discrete, DC-coupled Class A preamplifier output to drive power amplifier.
INPUT 1 - INPUT 4
Balanced XLR inputs to connect balanced sources.
INPUT 5 - INPUT 6
Single-ended RCA inputs to connect single-ended sources.
INPUT 6 is also a dedicated "Tape Input" (Please see MONITOR function.)
Balanced Connections
All Gryphon products follow the AES standard for balanced connections:
1. Ground 2. Positive 3. Negative
Gryphon recommends the use of dedicated, XLR-balanced interconnect cables.
Avoid the use of RCA-to-XLR adaptors as they will degrade system performance.
Commander Preamplifier Rear Panel
