Conventional Reflective Beam Detector
Installation and Operation Manual The Intelligent Solution
9
Detector
Detector
Reflector
Reflector
7m
8m
Fig. 6
d) For gable structure with space height about 8m, the
detector and reflector should be mounted on the two facing
walls 1.5m from the gabled girder, refer to Fig. 7.
