GT Force 27.5 - Replacement Parts

20
134937 Rev 1.
EnglishForce / Sensor - Owners Manual Supplement
REPLACEMENT PARTS
1
2
4
8
10
16
25
26
27
28
29
32
34
35
13
14
15
20
22
23
3
5
9
11
17
24
30
31
33
7
18
19
6
D
2
8 N·m
1.5 N·m
B
B
C
C
G
2
7 N·m
2
5 N·m
2
2 N·m
24
33
34
34
2
A
17
A
F
E
O
L
21
N
N
A
I
B
I
B
M
J
K
NGLI-2
1 N·m
5 N·m
C
H
1.5 N·m
2
8 N·m
I
B
2
5 N·m
Standard
Direct Mount
ID Part Number Description FORCE SENSOR
A K36038
Force/Sensor Shock Bolts and Flip
Chips
✔ ✔
B K36008 Force/Sensor Pivot Link CS Bearings
✔ ✔
C K36009
Expanding Axle Hardware 79mm and
87mm
✔ ✔
D K34009 Force/Sensor DT Protector
✔ ✔
E K32008 GT Mountain Cable Guide x4
✔ ✔
F K22059 GT ISCG Mount 3 Bolt
✔ ✔
G CK3187U00OS Grommets
✔ ✔
No. QTY Bearing Dimension (mm)
10 4 10 ID x 22 OD x 6 H
24 2 15 ID x 24 OD x 5 H
25 4 15 ID x 28 OD x 7 H
33 2 17 ID x 30 OD x 7 H
