TECHNICAL INFORMATION
Specifications
Item Specification
Model
Force Sensor
Wheel Size 27.5 in 29 in
Rear Travel 150 mm 130 mm
Head Tube UPR: 1-1/8 in, LWR: 1-1/2 in
Headset Integrated, 1-1/8 in - 1-1/2 in
Bottom Bracket: Type/ Width BSA / 73 mm
Front Derailleur N/A
Seat Post: Dia./Binder 31.6 mm/ 34.9 mm
Min. Seat Post Insert 100 mm
Tire Size x Max. Width
(measured)
27.5 in x 2.5 in 29 in x 2.35 in
Max. Fork Length 550 mm 540 mm
Rear Shock: Eye-To-Eye / Stroke /
Bushing Width
185 mm x 55 mm
Metric Trunnion
185 mm x 50 mm
Metric Trunnion
Sag (measured at shock) 12.5 mm 12 mm
Chain Guide ISCG 05
Rear Brake: Mount Type /
Min/Max Rotor Dia.
Post Mount / 180 mm
/ 203 mm
Rear Axle: Type/Length
Maxle TA / 148 x 12mm,
180 mm Length
Intended Use
ASTM CONDITION 4,
All-Mountain
Max. Weight Limit
Total (rider+all equipment):
305 lbs / 138 kg
