Guardian DCR2 User Manual

3
DCR2 Specification
Electrical Rating
Input
AC 220V 50/60Hz
Max. Current
2A
Power
100W
Standby Power
<2W
Motor
Type
DC 24V
Max. Capacity
1000N
Recommended Lifting Forces
Max. Lifting Force
60kg
Rated Lifting Force
40kg
Door Type
Max. Door Size
20.5m
2
Max. Door Height
4.6m
Door Travel Limits
4.5 turns of door drum approx.
Courtesy Light
Light Source
6 x Ultra Bright LEDs
Lighting Time
2.5 minutes
Transmitter
Frequency
433MHz
Operation Range
50m (open field)
Coding Type
Fixed-code
Battery
12V (A23 Alkaline) x 1
Features
Soft opening and closing
Safety reverse on closing and stop on opening
Digital interface for RH/LH setting, force adjustment, etc.
Miscellaneous
Operating Temperature
-20
o
C ~ +50
o
C
Dimension (mm)
434 L x 248 W x 190H
Weight
5.4kg approx.

Guardian DCR2 Specifications

General

Brand	Guardian
Model	DCR2
Category	Garage Door Opener
Language	English
