Guardian DCR2 - Pre-Installation Notes

4
Table of Contents
Pre-Installation Notes 4
Important Notices 5
Installation Instructions 6
Connectors 7
Setting Direction of Operation 8
Setting UP-Limit 9
Setting DOWN-Limit 10
Sensitivity Auto-Learning 11
Manual Sensitivity Adjustment (For Installers Only) 12
Programming Transmitter 13
Setting Auto-Closing Timer 14
Trouble-Shooting 15
Parts Breakdown 16
Parts List 17
Warranty 18
Pre-Installation Notes
The operator may be fitted to either the RIGHT or LEFT hand side of the roller door.
Check that there is sufficient side clearance to fit the operator unit as below listed:
Door Type
Minimum side clearance
“A” Series (1) (25mm deep tracks)
90mm
“AA” Series (2) (50mm deep tracks)
115mm
All doors with Windlock Tracks subject to Drum Position
140mm
Ensure there is a properly earthed mains supply socket adjacent to where the operator is to be fit-
ted.
If the operator is being fitted at the same time as the new door installation, read these instructions in
conjunction with the door installation instructions.
If the operator is being retro-fitted, make sure the door operates smoothly and is properly balanced.
N.B.: SPECIAL CARE SHOULD BE TAKEN IF RE-TENSIONING OF THE DOOR IS REQUIRED.
