Guardian DCR2 User Manual

7
Connectors
I. Main Control Panel
LED Indicators
UP RADIO SET
FORCE
GND
Photo Eye Selection
Jumper off — Selected
Ext. Aerial
DC 24V
Jumper on — Unselected
Photo Eye
Push Button
Manual Operate
Button
II. Miscellaneous Control and Terminals
Auto-Close Timer
LED Light
Backup Bat-
* Auto Close Timer function will only work when Photo Eye System is properly installed.
To activate Auto-Close Operation
Turn the knob towards “ + ” for maximum delay time of
2.5 minutes.
To deactivate Auto-Close Operation
Turn the knob fully towards “－ ”.
WARNING: This operator system is equipped with an unattended operation feature
when Photo Eye System is applied. The door could move unexpectedly.
NO ONE SHOULD CROSS THE PATH OF THE MOVING DOOR!
_
OFF
+
2.5 min
!
