operations manual Model 2606A/2606A-B

Display Operating condition

WhentheredLEDison,itindicatesthatyourbatteryisdis-

chargedandthe2606Aisrechargingatthe"BULK"rate(stage1).

This charging rate is 6 Amps.

WhiletheredLEDison,thevoltagemeasured(withthecharger

on)willbeapprox.11.8to14Volts.

IftheredLEDstaysonformorethan24hours,refertoProblem1

in the troubleshooting section in this manual.

WhenboththegreenandtheredLED’sareon,the2606Ais

chargingatthe"FINISHING"rate.(stage2).Duringthissecond

chargingstage,thechargerholdsthebatteryvoltageatap-

proximately14.6VDC,andthengraduallyreducestheamountof

current(Amps)itdeliverstothebattery.Bydoingthis,thebattery

is able to “absorb” the last 10% of charge as quickly as possible

withoutbecomingoverheated.

IfbothLED’sstayonlongerthan24hours,refertoProblem2in

the troubleshooting section in this manual.

WhenthegreenLEDison,the2606Aischargingata"FLOAT”

or“MAINTENANCE"rateoflessthan1.5Amps,(stage3).Your

batteryisnow90%chargedandreadyforuse.This"oat"charg-

ing current will gradually decrease to as low as 0.1 Amps as the

batteryreaches100%charge.Itwillnowbekeptatfullcharge

withoutover-charging.

IfthegreenLEDstaysonwhenyourbatteryisknowntobelow,

refertoProblem3inthetroubleshootingsectioninthismanual.

WhentheredLEDisashingonandoff,the2606Aisconnectedin

reversepolarity(positivechargeroutputterminaltonegativebattery

postandnegativechargeroutputterminaltopositivebatterypost).

Meaningthechargerisdisabledandnocurrentisbeingdeliveredto

the battery.

4. OPERATING THE CHARGER

THE LED FUNCTION CHART BELOW DESCRIBES THE CHARGING PROCESS.
