Fig. 1

Fig. 2

Installation of GH3 Horizontal lifter

Use the oval hook to install the Horizontal

lifter. (Fig. 1 and 2)

Important:

Check that none of the lifting straps

are twisted after the installation of the

GH3 Horizontal lifter

1.09 Lifting sling

A lifting sling with four to six lifting straps designed for mounting on hooks

should be used when using a Guldmann lifting hanger. Place the straps on

the hooks.

Slings made by other manufacturers

Guldmann shall not be liable for faults or accidents that may occur as a

result of using lifting slings made by other manufacturers.

If there is any doubt about the selection or use of a lifting sling,

please contact your supplier.

Guldmann shall not be liable for faults or accidents due to incorrect use of

the lifting sling, or for reasons of inadequate attention on the part of the carer

or user.

Working with the GH3

The GH3 runs easily in the rail system and does not have any special

requirements for space or power in connection with moving. Attention can

thus be fully focused on the user’s functional level and the helper’s technique.

If the hoist is used correctly, the user should only be lifted to the extent that

she/he is clear of the surface and should be moved at this height.
