7.00 Certicates
UL 60601-1 UL No. 305250
EN/ISO10535 HMI No. 08.49A, 09.14A, 09.15A
8.00 Technical specications
Example: GH3+ 350 122 1000
GH3
+ 350 1 2 2 1 0 0 0
Hand control
w/o Service module
w/o CLM module
Scale module
2 horizontal drive motors
2 lifting motors
1 lifting strap
Safe Working Load SWL: 350 kg
+
Ceiling hoist, type GH3
GH3 Lifting modules, version type nomenclature
Guldmann
hoist type
Product
line
Load in
kg
Number
of lifting
straps
Number
of lifting
motors
Number of
horizontal
drive
motors
Scale
module
CLM
module
Service
module
User
interface
GH3 (x) xxx x x x x x x x
GH3 200 1 1 1
250 1 1 1
+ 250 1 1 1 None : 0
Scale : 1
None : 0
CLM : 1
Cong : 2
None : 0
Service: 1
Cong : 2
Hand
control: 0
IR : 1
300 1 2 2
350 1 2 2
Twin 250 2 2 0
500 2 2 0
GH3 X Y Z Z Z Q Q Q Q
