700 1060hPa
-10 40°C
14 104°F
30 70%
29
© Guldmann GB/US-05/2010 • # 550393
© Guldmann GB/US-05/2010 • # 550393
© Guldmann GB/US-05/2010 • # 550393
© Guldmann GB/US-05/2010 • # 550393
Lifting sling with undivided leg straps (Sit-On sling):
It is an advantage to position the lifting sling with the narrow side facing the
user. Hook the back straps on the hoist onto the hooks closest to the user
and the leg straps to the hooks farthest away from the user.
Horizontal lifter, foldable 28444
The horizontal lifter is a lifting device which is used together with a hoist
and rail systems to move people in a horizontal position. It can be stored
completely or partially folded in order to minimise space requirements, or it
can hang ready to use in the hoist.
The horizontal lifter may be used only for horizontal relocation of people lying
on a level, horizontal surface. The person must be lying on a Guldmann sling
or on another suitable sling. A level surface can be, for example, a bed, a
stretcher or the oor.
Batteries
NiMH Battery 24V/2800mAh, Guldmann type number 550574.
Transformer
Transformer, Class 1, Guldmann item number 550391
Transformer, Class 2, Guldmann item number 550388 (EU),
550387 (US/CAN)
3.00 Transport and storage
Guldmann recommends that the GH3 is always transported and stored
in the original packaging.
Key to symbols on the GH3 packaging:
The GH3 should be stored at:
– Temperatures between -10 and +40°C / 14 and 104°F
– A relative air humidity of between 30 and 70 %
– An air pressure of between 700 and 1060 hPa
– This side up
