Using tilt function on GH3
The GH3 has a tilt function. This function can only be used with
a horizontal lifter. (See section 2.03 for positions of hand control buttons)
1. When the buttons 1 or 2 are pressed
both hoists will lift or lower the
horizontal lifter.
2. When the button 3 is pressed only the
leader hoist lifts the horizontal lifter.
3. When the button 4 is pressed only the
leader hoist will lower the horizontal
lifter.
