GDS-800 Series Digital Storage Oscilloscope Operation Manual
77
Power Source：
Line Voltage Range 100V ~ 240V AC, auto selection
Line Frequency 47Hz ~ 63Hz
Power Consumption 45 Watts, 65VA maximum, with Fan
Fuse Rating 2 Ampere Slow, 250V,
Interface：
Only for GDS-806S/C and GDS-810S/C with
interface option, GDS-820S/C, and
GDS-840S/C
Centronics port
A 25-pin IBM PC type, parallel printer
interface
Printer Compatibility
HP LaserJet with HP PCL5 Black & white @150×150dpi
HP DeskJet Black & white @150×150dpi
USB Interface USB 1.1 & USB 2.0 Full speed
compatible.
Device only, not support USB printers
RS-232 Interface A DB 9-pin male DTE RS-232
interface
GPIB Interface
Only for GDS-806S/C and GDS-810S/C with
interface option; GDS-820S/C and
GDS-840S/C with GPIB option
Option
Fully programmable with IEEE488.2
compliance
