GDS-800 Series Digital Storage Oscilloscope Operation Manual
76
Trigger Frequency Counter
Readout Resolution 6 digits
Frequency Range 20Hz minimum to rated bandwidth
Accuracy ±2%
Signal Source All available trigger source except the
Video trigger mode
Control Panel Functions：
Autoset “Autoset” adjust Vertical VOLT/DIV,
Horizontal SEC/DIV, and Trigger level
automatically.
Save/Recall Up to 15 sets of measurement
conditions can be saved and recalled
Waveform Trace Save/Recall 2 sets of waveform can be saved and
recalled
Display System：
LCD Type
5.7 inch Mono LCD (320*240) for
GDS-806S, GDS-810S, GDS-820S,
GDS-840S
5.7 inch Color LCD (320*240) for
GDS-806C, GDS-810C, GDS-820C,
GDS-840C
Waveform Display Graticule
8 ×10 divisions、
8 ×12 divisions（menu off）
Display Contrast Adjustable
