GDS-800 Series Digital Storage Oscilloscope Operation Manual
7
2. General Description and Features
The GDS-806/810/820/840 is a useful, 2 channel digital storage oscilloscope with
following features:
z Up to 250MHz (60MHz for GDS-806S/C, 100MHz for GDS-810S/C, 150MHz for
GDS-820S/C and 250MHz for GDS-840S/C series) repetitive bandwidth and
100MSa/s sample rate per channel (25GSa/s E.T. sample rate per channel).
z Up to 10ns peak detection for glitch capture.
z A large 5.7” mono or color LCD display (monochrome display for GDS-806S,
GDS-810S, GDS-820S and GDS-840S, color display for GDS-806C,
GDS-810C, GDS-820C and GDS-840C).
z Two input channels, each with a record length of 125k points and 8 bits vertical
resolution. Both channels acquire waveforms simultaneously.
z Time base: 1ns/div~10s/div.
z 6-digit trigger frequency counter.
z Auto-setting for quick setup and hands-free operation.
z Three Acquisition modes: Sample, peak detect, and average mode.
z Cursors and 15 continuously update, automatic measurements: V
hi
, V
lo
, V
max
,
V
min
, V
pp
, V
average
, V
rms
, V
amp
, rise time, fall time, duty cycle, frequency, period,
positive width, negative width.
z 15 sets memory for front panel setting save & recall.
z 2 sets memory for waveform trace save & recall.
z 100 sets arbitrary waveforms can be input as templates for Go/NoGo function.
z FFT spectrum analysis.
z Two valuable “Program mode” and “Go-No Go” function are included.
z Advanced video and pulse width trigger.
z A large 8 ×12 divisions（menu off）waveform display graticule.
z RS-232, Centronics port, USB output and GPIB interface module are supported.
z Multi-language operating environment are supported, there are English,
tradition Chinese, simplified Chinese, French, German, Italian, Korean, Russian,
Finnish, Spanish and Polish are supported for this moment.
