GDS-800 Series Digital Storage Oscilloscope Operation Manual
8
The advance 32-bit microprocessor controlled GDS-800 series Digital Storage
Oscilloscope has been designed for a wide multitude of applications in service and
industry. For ease of operation the “Autoset” function allows for signal related
automatic setup of measuring parameters. On-screen readout and cursor functions
for voltage, frequency and frequency measurement provide extraordinary
operational convenience. Fifteen different user defined instrument settings can be
saved and recalled without restriction. The built-in RS-232 serial interface allows for
remote controlled operation by a PC. A six digits frequency counter provides extra
value for users. The USB port is able to dump entire scope’s LCD screen to
computer via specific software. The valuable “Program” mode is able to help users
to record all the necessary measuring steps and replay all steps again. The special
“Go-No Go” function is very useful for the people who need to distinguish the pass
or failure for particular conditions.
The instrument offer the right combination of triggering control, frequency response,
and time base versatility to facilitate measurements in a wide range of applications
in laboratory as well as in field service use. It is another example of our dedication to
engineering excellence.
