GDS-800 Series Digital Storage Oscilloscope Operation Manual
75
Signal Acquisition System：
Real-time Sample Rate 100MSa/s maximum on each channel
Equivalent Sample Rate 25GSa/s E.T. maximum on each
channel
Vertical Resolution 8 Bits
Record Length / Channel 125k Points
Single Shot Record Length 125k Points
Single Shot Bandwidth 10MHz
Acquisition Mode Sample, Peak Detect, Average
Peak Detection 10ns (500ns/div ~ 10s/div)
Average
2、4、8、16、32、64、128、256、
256
Cursors and Measurement：
Automated Voltage Measurement
V
pp
，V
amp
，V
avg
，V
rms
，V
hi
，V
lo
，V
max
，
V
min
Automated Time Measurement Freq, Period, Rise Time, Fall Time,
Positive Width, Negative Width,
Duty Cycle
Cursors Measurement Voltage difference between cursors (∆V)
Time difference between cursors (∆T)
Reciprocal of ∆T in Hertz (1/∆T)
