GDS-800 Series Digital Storage Oscilloscope Operation Manual
74
Horizontal：
Range 1ns/div ~ 10s/div (1-2-5 increments)
Modes Main, Window, Window Zoom, Roll,
X-Y
Accuracy
0.01﹪
Delay Range
Pre-trigger 20 div maximum
Post-trigger 1000 div
X-Y mode：
X-Axis Input
Channel 1 (CH1)
Y-Axis Input Channel 2 (CH2)
Phase shift ±3 at 100kHz∘
