GW Instek GPT-9800 - Main Features

GETTING STARTED
11
Main Features
Performance
 ACW: 5kVAC
 DCW: 6kVDC
 IR: 50V~1000V (50V steps)
 GB: 3A~30A
Features
 Ramp up time control
 Safety discharge
 100 test conditions (MANU mode)
 100 automatic tests (AUTO mode)
 Over temperature, voltage and current
protection
 Pass, Fail, Test, High Voltage and Ready
indicators
 PWM output (90% efficiency, increased
reliability)
 Interlock (configurable).
Interface
 Remote control start/stop interface terminal
 RS232/USB interface for programming
 Optional GPIB interface for programming
 Signal I/O port for pass/fail/test monitoring
and start/stop control/interlock
