Remote Controller Operation
Description
The GPT-9000 accepts external remote
controllers with a START and STOP button. To
use the REMOTE terminal, the GPT-9000 must
first be configured to accept a remote controller.
Operating a remote controller is the same as
operating the START and STOP buttons on the
front panel.
Steps
1. Turn off the power.
2. Insert the lead of remote controller
into the REMOTE terminal.
REMOTE
3. Turn on the power to the tester.
4. Configure the Start Ctrl option to
REMOTE CONNECT in the
Common Utility menu.
Page 76
5. The tester will now only be able to
start a test using a remote
controller.
6. To return the operation control to
the front panel, configure the Start
Ctrl option to FRONT PANEL.
Page 76
