GW Instek GPT-9800 - Edit Automatic Test Settings

OPERATION
81
Edit Automatic Test Settings
Background
To edit an automatic test, the tester must be in
EDIT status.
Any settings or parameters that are edited only
apply to the currently selected AUTO number.
Steps
1. Press the EDIT/SAVE key when in
VIEW status to enter the EDIT
status. This will enter the EDIT
status for the chosen AUTO
number.
EDIT/SAVE
I R G B
m A
A CW D CW A D D
E
F R E Q = 0 H z 6
0 100
k V
RA C = F FO
IDE
MT I E = 0 0 1 . 0 SR
0 0 m AER F =# 0 .0MA U OT N A_
1 . 0 0 m AIH ES = 0T
0 0 . 1 S0A M P =R
T
1A U T O = 0 0 1 - 0 0
EIV W
2. The Status changes from VIEW to EDIT. The
tester is now ready to edit the current AUTO
test.
Note
Pressing the EDIT/SAVE key again will save the
settings or pressing the ESC will cancel the
settings for the current AUTO test and return back
to VIEW status.
