12
Figure 14 Physical drive detail screen
Table 4 Parameter description
ID
Physical drive slot information. Options include:
• 0—Slot for physical drive marked Bay 1.
• 1—Slot for physical drive marked Bay 2.
Status
Physical drive status. Options include:
• Unconfigured—Not used by any RAID array and unidentifiable
in the OS.
• Assigned—Used by a RAID array and identifiable in the OS.
Model Name Physical drive model.
Serial Number Physical drive serial number.
FW Version Physical drive firmware version.
Size Physical drive capacity.
Viewing logical drive information
1. Access the storage controller configuration screen, select Virtual Device Information, and
press Enter.
