7 Decommissioning
Press the On/Off key (68) on the release module RM03 briefly to switch off the LED
illumination after the examination. This does not switch off the camera. This is
signaled with green pulsing. Pressing the key for approx. 3 sec. switches off the re-
lease module completely and the operational control LED (67) goes out. The cam-
era has no separate On/Off switch. It switches off automatically when the connector
box CB01 is switched off.
NOTE!
The On/Off key on the release module RM03 does not disconnect the
device from the electric mains. Disconnect the power supply from the
mains by unplugging the mains connector if you do not intend to use it
for an extended period of time.
8 Technical data
8.1 Power supply
Type EDACPOWER Electronics Co
Model EM10682H
Mains voltage 100 − 240 VAC
Current consumption 2.0 - 1.0 A
Operating frequency 50 − 60 Hz
8.2 Dimensions
IM 910 set
Weight 4.5 kg (incl. packaging)
Dimensions CM04 (L × W × H) 173 × 127 × 82 mm
Packaging (L × W × H) 380 × 270 × 130 mm
8.3 Minimum network requirement for operation with EyeSuite
Ethernet interface (for PC and switch) 1000BASE-T (1 Gbit/s)
NOTE!
Minimum requirements for PCs can be found in the EyeSuite instructions
for use.
8.4 Allowed monitor resolutions for standalone operation
1920 x 1080 pixel resolution (FHD)
2560 x 1440 pixel resolution (QHD)
3840 x 2160 pixel resolution (4K UHD)
1)
1) Limited to 30 frames per second
8.5 Camera
Camera beam mono Beam path right (from the point of view of the
doctor)
Camera beam stereo Beam path left and right
Interface CoaXPress CXP
Frame rate 30 fps (frames per second)
Image file format jpg
Video file format mp4
Power consumption 24 VDC
/ 420 mA
8.6 Connector box CB01
Storage size 256 GB
Interface HDMI, DisplayPort (DP), LAN
Power consumption Input
Output
Output
24 VDC / ±5% / 2 A
24 VDC / 1 A (CAN-BUS)
24 VDC / 700 mA (CXP)
