10
INSTALLATION
June 1999
96-8000
MOVING T HE C RATE
CAUTION!
THE VMC CRATE CAN ONLY BE MOVED WITH A FORKLIFT.
CAUTION! The fork positions are marked on the crate. (Also, note that there are three skids at each side of
the pallet. The heavy part of the machine [the back] is positioned over the two skids that are closest together.)
If the fork positions are ignored, there is a good chance that the retaining bolts will be sheared off by the forks
and also that the machine will tip over when it is picked up.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Haas VF-6 and is the answer not in the manual?

Haas VF-6 Specifications

General IconGeneral
Machine TypeVertical Machining Center
Spindle Motor30 hp
Travels X Axis64 in (1626 mm)
Travels Y Axis32 in (813 mm)
Travels Z Axis30 in (762 mm)
Spindle Speed8, 100 rpm
Rapid Traverse on X25.4 m/min
Rapid Traverse on Y25.4 m/min
Rapid Traverse on Z25.4 m/min
