428

OPTIONS

96-8000

June 1999

M CODES

Only one M code may be programmed per block of a program. All M codes are effective or cause an action to

occur at the end of the block. The following M codes are used to program the APC:

M36 Hold until "Pallet Ready" button is pressed

M50 Perform pallet change

SAMPLE P ROGRAMS

Example #1:

Basic program using the "Pallet Ready" light on the APC.

Oxxxx

M36 (Flash "Pallet Ready" light - wait until PALLET READY button pressed to continue)

M50 (Perform pallet change after "Pallet Ready" button is pressed)

(USERs PART PROGRAM)

M99 (Repeat program)

Example #2:

Basic pallet change program that tracks which part is to be machined on each pallet.

Oxxxx

M36 (Flash "Pallet Ready" light - wait until PALLET READY button pressed to

continue)

M50 (Perform pallet change after "Pallet Ready" button is pressed)

If [#510 EQ 1] M98 (USERs PART PROGRAM #1)

If [#510 EQ 2] M98 (USERs PART PROGRAM #2)

M99
