VOLTAGE S ELECTION T APS
There are four labeled plastic terminal blocks. Each block has three connections for wires labeled 74, 75, and
76. Follow the instructions printed on the transformer.
SECONDARY C ONNECTION T O T1
The secondary output from T1 is 115V AC three-phase CB2 protects the secondary of transformer T1 and is
rated at 25 amps.
OPTIONAL 480 TRANSFORMER
Voltage Selection Taps for the 480 Transformer:
Right to left:
354 to 376
377 to 402
403 to 428
429 to 457
458 to 488*
* 480 V transformer has additional terminal block

Haas VF-6 Specifications

General

Machine Type	Vertical Machining Center
Spindle Motor	30 hp
Travels X Axis	64 in (1626 mm)
Travels Y Axis	32 in (813 mm)
Travels Z Axis	30 in (762 mm)
Spindle Speed	8, 100 rpm
Rapid Traverse on X	25.4 m/min
Rapid Traverse on Y	25.4 m/min
Rapid Traverse on Z	25.4 m/min
