Table 2 Screen icon descriptions (continued)
Icon Function Description
Test wizard Test and report wizard for ISO, EU-GMP, FS or BS classification compliance. Refer to
Set up the Test and Report Wizard on page 34.
Return Return to the previous screen or menu.
Configuration
About configuration
This section describes tasks that are usually done at the initial commissioning stage. Other tasks are
done as updates to the particle counter are needed.
Note: If user passwords are set, the user must be logged in as an administrator to configure the particle counter.
About Basic and Advanced operation
At startup, the user can set the operation mode to Basic or Advanced settings.
Use the Basic mode to:
• Do all particle measurement functions
• Save run data in the buffer
Use the Advanced mode to:
• Export dialogs
• Measure air velocity
• Set analog alarms
• Set standards wizards and reports
• Backup, restore and restart
• Copy a configuration
• Set the network protocol (serial, Ethernet, Wi-Fi)
• Manage areas and locations
• Manage user counts and security
• Set user-configurable particle sizes
• Filter data
Set the operation mode at initial startup
To set the operation mode:
1. Power on the instrument.
2. While the operation mode selection screen shows, do one of the actions that follow:
• Select BASIC or ADVANCED.
• Wait 10 seconds. The instrument will start in the selected operation mode.
Change the operation mode
Only permissions in the Advance Operation mode allow a user to change the operation mode. To
change operation mode from Advanced to Basic mode:
1. On the Counter Navigation screen, push SYSTEM.
2. Select the Custom tab.
English
19
