Modbus Register Information
cal_L2 40077 Float 2 R cal. point 2
cal_L3 40079 Float 2 R cal. point 3
cal_mes 40081 Float 2 R m - calibration
cal_ref 40083 Float 2 R r - calibration
cal_intensity_mes 40085 Float 2 R intensity m - calibration
cal_intensity_ref 40087 Float 2 R intensity r - calibration
cal_ext 40089 Float 2 R extinction - calibration
process 40091 Unsigned Integer 1 R/W process register
menu 40092 Unsigned Integer 1 R menu state
gain_ref 40093 Integer 1 R
low byte = gain ref-channel, high
byte = second cap. on/off
gain_mes 40094 Integer 1 R
low byte = gain mes-channel, high
byte = second cap. on/off
wiper_lim_a 40095 Integer 1 R wiper limit a
wiper_lim_b 40096 Integer 1 R wiper limit b
wiper_lim_out 40097 Integer 1 R wiper limit out
prg_vers 40098 String 4 R program version
ser_no 40102 Integer 2 R serial number
cal_out_cfg 40104 Integer 1 R cal. Output mode
user_cal_int 40105 Integer 1 R/W user calibration interval
wiper_current 40106 Integer 1 R wiper motor current in mA
resp_time_min 40107 Integer 1 R response time in min
flash_per_fil 40108 Integer 2 R flash per filter
cm1 40110 Float 2 R/W meas. Cap 1
cm2 40112 Float 2 R/W meas cap 2
cr1 40114 Float 2 R/W ref cap1
cr2 40116 Float 2 R/W ref cap2
lambda_m 40118 Float 2 R/W lambda meas
lambda_r 40120 Float 2 R/W lambda ref
transm_m 40122 Float 2 R/W transmission meas
transm_r 40124 Float 2 R/W ransmission ref
cal_menu 40126 Unsigned Integer 1 R/W cal menu
wiper_menu 40127 Unsigned Integer 1 R/W wiper menu
maint_menu 40128 Unsigned Integer 1 R/W maint_menu
service_menu 40129 Unsigned Integer 1 R/W service menu
flash_repl 40130 Unsigned Integer 1 R/W flash replaced question
edit_menu 40131 Unsigned Integer 1 R/W edit menu
def_menu 40132 Unsigned Integer 1 R/W default menu
filter_data_menu 40133 Unsigned Integer 1 R/W filter data menu
prod_date 40134 Time 2 R production date
sensor_type 40136 String 8 R/W sensor type
filter_set 40144 String 3 R/W filter set
user_cal_counter 40147 Integer 1 R user cal. Counter
pos_out_en 40148 Unsigned Integer 1 R/W pos. Out enable
Table 3 Sensor Modbus Registers (continued)
