4
Specifications
NITRATAX sc sensor material
Sensor
Sensor enclosure Stainless steel 1.4571 Stainless steel 1.4581
Wiper axle Stainless steel 1.4104 Stainless steel 1.4571
Cable gland Stainless steel 1.4305
Profile carrier 1 mm/2 mm Stainless steel 1.4310
Wiper arm 5 mm Stainless steel 1.4581
Wiper profile Silicone
Measuring windows SUPRASIL (quartz glass)
Enclosure seals Silicone
Seal, cable gland PVDF
Sensor cable
PUR
10 m (33 ft) standard
Optional extension cables available in 5, 10, 15, 20, 30, 50 m
Total maximum length: 60 m (196 ft)
Struts
Adaptor for filtration
sensor
Stainless steel 1.4308
Struts Stainless steel 1.4301
Flow through cell (bypass)
Measuring cell PVC
Seals EPDM
Glands PVDF
Sample tube PVC
Component NITRATAX plus sc NITRATAX eco sc NITRATAX clear sc
