1. Push the main menu icon, then select Controller > Connectivity > HCNB.
2. Select Topology list.
Option Description
Topology List Shows a list with all of the controllers with which the controller communicates
successfully. Shows the sensors connected to each controller.
• Static controllers (future option, currently not available)—Shows the
controllers and sensors manually added with the Topology configuration
option.
• Auto detected controllers—Shows the controllers and sensors automatically
found on the HCNB.
3. Push APPLY.
3.3 HCNB—View statistics
The Statistic menu shows information about the data flow in the network.
1. Push the main menu icon, then select Controller > Connectivity > HCNB. Then, select
Statistic.
2. Select an option.
Option Description
Received Shows the number of packages received in the HCNB.
Transmitted Shows the number of packages transmitted in the HCNB.
3. Push APPLY.
Section 4 Claros configuration
Claros is a web-based suite of solutions that mixes instrument, data and process management.
Mobile Sensor Management (MSM) is part of Claros. MSM lets the user see the measurements and
instrument condition anytime, anywhere on a web-enabled device. MSM shows upcoming
maintenance tasks and gives simple maintenance instructions. Based on the controller configuration,
the controller can connect to Claros to use MSM. Make sure that the controller is connected to the
internet with LAN, Wi-Fi or cellular network.
When the controller connects to the internet with a cellular network, the controller can share the
internet connection with other controllers in the HCNB.
Configure Claros on the controller as follows:
1. Configure internet connection. Refer to the controller documentation.
2. Push the main menu icon, then select Controller > Connectivity > Claros. Set to on.
3. Add the controller to the user Claros account. On a web-enabled device open Claros and follow
the instructions on the screen.
Section 5 Network topologies
The topologies that follow are applicable to the SC4500 network configuration.
English
9
