18
Installation
Figure 8 SS7 sc and SS7 sc-HST installation drawing
1 Door hinges (4x) 7 Ball valve
2 Flow multiplier (SS7 sc-HST only) 8 ¾-in. NPT nipple
3 Ventilator (2x) 9 1-in. NPTF bulkhead fitting
4 Cable assembly 10 ¾-in. NPTF bulkhead fitting
5 Enclosure door latch (4x) 11 Air purge fitting
6 Drain trap (SS7 sc-HST only)
