Maintenance
Figure
20
D
etector
assemb
ly
replacement
1
Detector assembly (Cat. No. 71221-00)
6
Clamping fingers
2
Light source assembly power connector
7
Bushing
3
Cable clamp
8
Nut
4
Blunt object
9
Detector assembly cable
5
S
train relief
