- 11 -
Service Manual
Model No.:48E2500
*CN7 (3PIN/2.0): EXT-LINE OUT CONNECTOR
NO. SYMBOL DESCRIPTION
1L_RO Audio Lineout Right Channel Output
2GND Ground
3L_LO Audio Lineout Left Channel Output
CNB1 AC INPUT CONNECTOR
NO. SYMBOL DESCRIPTION
1L
LIVE
2NC NoConnection
3N
NEUTRAL
7. Electrical Characteristics
7.1 Input Electrical Specifications
Input Minimum Nominal Rating Maximum Unit
Voltage 90 115/230 100~240 264 Vac
Current —— —— —— 1.5 A
Frequency 47 60/50 —— 63 Hz
Efficiency
≥80%min(Full load with input AC voltage of 115Vac @ 60Hz
and 230V ac @ 50Hz)
Standby Power Consumption
0.5W At 240Vac input and no load condition
Inrush current (cold start) 70 Amperes @ 230Vac / 50Hz input
Leakage Current Less Than 0.35mA, 240Vac input
Input Fuse T3.15A/250Vac
