Haier GE AZ45E07DABW5 - Heater Assembly Removal Procedure

– 45 –
Heater Assembly
Heater Assembly
Remove six screws to remove the end cap to access the heater assembly. Two screws are used
to secure the bracket attached to the indoor coil and end cap. After disconnecting the wire harness
from the board and removing one ground screw, the heater assembly will slide out the left side of the
Zoneline.
