14
2. Align the holes in the bottom plate with the holes in the bottom of the washer.
IMPORTANT: To avoid damage to the washer, make sure the bottom plate is
positioned correctly before fastening the plate to the washer.
3. Using a Phillips screwdriver and the 6 bottom plate screws (provided), insert
each screw through the bottom plate and into the bottom of the washer cabinet.
Tighten the screws completely.
FRONT
FACE TO FLOOR
a Bottom Panel Screw
STEP 4 - INSTALL CASTERS (OPTIONAL)
1. Unscrew and remove the 4 xed leveling legs.
2. Screw each of the 4 casters into the holes in the base of the washer. Using a
wrench, tighten the locking nut to the bottom of the washer.
a Caster Wrench
b Caster
3. Press the tab on each caster into the down position to lock the caster.

Table of Contents

Other manuals for Haier HLP21N

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Haier HLP21N and is the answer not in the manual?

Haier HLP21N Specifications

General IconGeneral
Water consumption per cycle- L
Energy consumption washing per cycle- kWh
Dimensions (WxDxH)447 x 438 x 760 mm
Power requirements120V, 60Hz
Door hingeUp
Drum volume28 L
Loading typeTop-load
Drum materialStainless steel
Product colorWhite
Built-in displayNo
Appliance placementFreestanding
Drum capacity- kg
Spin-drying class-
Maximum spin speed700 RPM
Number of washing programs3
Package weight51800 g
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth438 mm
Width447 mm
Height760 mm
Weight43000 g
