15
STEP 5 - LEVEL THE WASHER
IMPORTANT: Proper leveling of the washer will help reduce noise and vibration.
1. Using two or more people stand the washer upright.
NOTE: If you installed casters, unlock them by lifting up on the tab.
2. Place washer in its nal location. Check that the water and drain lines are not
strained or pinched. Make sure that all four feet are rmly in contact with the
oor and that the washer rests solidly in position.
3. Using a carpenter’s level, check to make sure the washer is level from side to
side and from front to back.
4. If the washer is not level, adjust the leveling feet or casters. Turn clockwise to
extend (raise the washer) or counterclockwise to retract (lower the washer).
NOTE: If the washer is inclined more than 2°, it will not operate.
FIXED LEVELING FEET
1. Loosen the adjustable large, outer ring, and then turn the center foot clockwise
or counterclockwise to adjust the height.
Raise Lower
a Outer Ring
b Center Foot
2. Once the washer is level, lock the position of each leveling foot by tightening the
large, outer ring.
CASTERS
1. Using the caster wrench turn the locking nut on the caster clockwise or
counterclockwise to adjust the height.
Raise Lower
a
b
a
b
a Locking Nut
b Caster Lever
To Next Page
