Haier HW100-B14979 Service Manual

Chapter 2 Product
●
Feature
2-1. Features
(1). 320mm diameter porthole, door may be open at a 175 degrees.
Facilitate view of wash process, facilitate unloading and easy to use with large port.
(2). Class A energy-saving
Scientific design for tub can reduce the use of water heavy during washing, consequently upgrade the
energy efficiency class to A,also use scientific washing
(3). Multi-gear speed controller
According to different costuming you can select corresponding spin speed from 0 to 1200 rpm.
(4). Unique gasket design featuring no residual water hidden inside.
By the unique gasket washing machine can left no residual water hidden between outer drum and front
board.
(5). Delay time adjustive.
According to different costuming you can select delay time from 0.5h to 24h.
DD motor
979
5

Haier HW100-B14979 Specifications

General

Door color	Black
Door hinge	Left
Motor type	Beltless
Water fill	Cold
Control type	Rotary, Touch
Display type	LED
Loading type	Front-load
Tub material	Plastic
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Custom panel-ready	-
Illumination color	Blue
Appliance placement	Freestanding
Drum capacity	10 kg
Cycle time (max)	238 min
Delay start (max)	24 h
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	69 dB
Noise level (wash)	- dB
Number of washing programs	14
Maximum washing temperature	90 °C
Power plug type	Type F (CEE 7/4)
AC input voltage	220 - 240 V
Energy efficiency scale	A to G
Power consumption (standby)	0.45 W
Water consumption per cycle	51 L
Energy consumption washing per cycle	0.512 kWh
Package depth	646 mm
Package width	653 mm
Package height	890 mm
Package weight	82000 g

Weight and Dimensions

Depth	620 mm
Width	590 mm
Height	850 mm
Weight	77000 g
