INSTALLATION INSTRUCTIONS
ENGLISH
6
A. Install the top mounting rail with 3 Type A screws.
STEP 4 - PREPARE THE AIR
CONDITIONER
CLICK
7RS
0RXQWLQJUDLO
B. Slide the side curtain panels into the side panel rails.
C. Slide left and right side curtain frames into top and
bottom rails. Make sure that side curtains snap into
side of the frames.
A. Measure the width of the window opening and mark
the center line on the inside window sill. Place the
unit in the window. Lower the window to hold unit in
place.
STEP 5 - INSTALL THE AIR
CONDITIONER IN THE WINDOW
:LGWKRIZLQGRZRSHQLQJ
&HQWHUOLQH
B. Set the air conditioner in the window so that is
centered. Place the air conditioner so that front edge
of the bottom mounting rail is against the back edge
of the sill.
C. Install the side bracket into the unit and into the
window sill using two 1” wood screws provided.
Repeat on other side.
