Haier Smart Power Series User Manual

161
Smart Power
ADH071M3ERG
PCB code 0151800267
SW3_1
SW3_2
SW3_3
Reserve
1 2 3 Description
0 0 0 OFF(default)
SW3_4
Slim duct/
Med ESP
duct
0 Slim duct
1 Med ESP duct
SW3_5
SW3_6
SW3_7
SW3_8
Wired
controller
indoor
address
（
Zone
address
）
5 6 7 8 Wired controller indoor address(Zone address)
0 0 0 0 0#
(
master
)(
default
)
0 0 0 1 1#
（
slave
）
0 0 1 0 2#
（
slave
）
0 0 1 1 3#
（
slave
）
… … … … ……
1 1 1 1 15#
（
slave
）
BM1 (1-ON, 0-OFF)
Capacity (SW1-1→SW1-3)
Room card
SW1-4
Running
mode
Unit Type Area
Description
SW1-1 SW1-2 SW1-3 SW1-5 SW1-6 SW1-7 SW1-8
1 1 0 --- --- --- --- --- ADH071M3ERG
--- --- --- 0 --- --- --- --- Room card invalid(default)
--- --- --- 1 --- --- --- --- Room card valid
--- --- --- --- 0 --- --- --- Heat pump(default)
--- --- --- --- 1 --- --- --- Cooling only
--- --- --- --- --- 0 --- --- Fresh air(default)
--- --- --- --- --- 1 --- --- Error alarm
--- --- --- --- --- --- 0 --- Filter alarm invalid(default)
--- --- --- --- --- --- 1 --- Filter alarm valid
--- --- --- --- --- --- --- 0 Used in American (default)
--- --- --- --- --- --- --- 1 Not used in American
