- 18 -
3.6. GPS Status Page
①
Receiver status The current GPS status.
②
Position of SAT. Position of the satellites.
③
SNB Graph Showing the WPT and the bearing.
④
Navigation Data Information of the various data.
* Color of the GPS status
Black: Tracked, but no signal
Blue: Tracked, but not used, Satellite
Green: Used Satellite
Light Blue: SBAS Satellite
④
①
②
③
